Demonstration of Zero-Knowledge Proof for Sudoku
Using Standard Playing Cards


We show a pictorial demonstration of a zero-knowledge protocol for Sudoku using playing cards. It corresponds to Protocol 3 in the paper.

The equipment needed is a blank board with the Sudoku grid drawn on it and several standard decks of cards with identical patterns on their back. Each card represents a value in the range 1-9 (the precise assignment is not important). The two participants are called prover and verifier. They both know a Sudoku puzzle and the prover knows (or so he claims) a solution to it. The prover wants to convince the verifier that he knows the solution without giving information about it.

The protocol:

  1. The prover places three cards on each cell. On filled-in cells of the puzzle he places three cards with the assigned value, faced up (this can be done by the verifier as well). On the rest of the cells the prover places the cards according to the solution, faced down.
  2. For each row, column and subgrid, the verifier chooses (at random) one of the three cards of each cell in the corresponding row/column/subgrid. and makes packets out of the chosen cards. I.e. he assembles the cards chosen for that row, columns or subgrid.
  3. The prover shuffles each of the 27 packets separately, and hands the shuffled packets to the verifier.
  4. The verifier turns over all the cards in each packet, and verifies that in each packet all numbers appear.

The soundness error of this protocol (the probability that a cheating prover succeeds) is 1/9. The protocol is zero-knowledge: for any verifier there exists a simulator that produces the same distributions of views that the verifier produces.

A demonstration of the Protocol



The equipment needed: several standard decks of playing cards
with the same background, and a 9 x 9 board.

The equipment needed for the zk sudoku protocol



The puzzle:

The Puzzle itself (picture of newspaper)





Step 1: The verifier (or the prover) places the cards according to the Sudoku puzzle.
Three card faced up on filled-in cells.

The verifier places the cards according to the Sudoku puzzle.



Step 1: The prover places cards on the remaining cells following his solution.
Three identical valued cards on each cell face down.

The prover places cards on the remaining cells following his solution.



Step 1: The entire board at the end of the step.

The entire board at the end of Step 1



Step 2: The verifier starts making packets, one for each column.
From each cell in each column one of the three cards is chosen at random.

Step 2: The verifier starts making packets, one for each column.



Step 2: A closer look.

Step 2: a closer look at the column packets



Step 2: Similarly, the verifier makes packets for the rows:

Step 2: Similarly, the verifier makes packets for the rows



Step 2: Finally, the verifier makes packets for the sub-grids; end of the step.

Step 2: Finally, the verifier makes packets for the sub-grids; end of the step.



Step 3: The prover turns over the cards faced up in each packet and shuffles them.

Step 3: The prover turns over the cards faced up in each packet and shuffles them.



Step 4: The verifier opens the packets and sorts to see that all 9 values appear in every packet.

Step 4: The verifier opens the packs and sorts to see that all 9 values appear in every packet.
